The VCC-VCL3M camera is compact, measuring approximately 29mm in size and weighing around 50g. The VCC-VCL3M an ideal choice for embedded systems that prioritize speed and size efficiency. With CameraLink Base configuration, you can select between 1Tap, 2Tap, or 3Tap output options. The corresponding frame rates for these options are 537.6fps (3Tap), 267.7fps (2Tap), and 133.8fps (1Tap).
TECHNICAL INFORMATION:
- 29mm cubic in size
- Global shutter type CMOS sensor
- Camera Link I/F
- ROI
- Sub-sampling
- External trigger
Quick Info for the CIS VCC-VCL3M
| Camera Series: | CL |
|---|---|
| Interface: | Camera Link |
| Manufacturer: | CIS |
| Resolutions: | Under 1 MP |
| Signal System: | Monochrome |
