JAI BM-500 Camera

The BM-500 CL is a new addition to the Basic tier of the C3 family.

It is a monochrome progressive scan camera with 5 million pixels resolution and Camera Link (CL) interface.

The camera operates at 15 frames/second in continuous mode even with a 5 megapixel resolution, thanks to a well-crafted analog front end design. Partial scan and binning modes are also provided.

The camera offers superb thermal management and pre-processing functions such as: white balance, LUT for compensating lighting condition and a blemish compensation function.

In common with all C3 Camera Suite models, the new BM-500 CL camera is supported by JAI’s SDK and Control Tool.

Dimensions (HxWxL): 55 x 55 x 55 mm.

FEATURES:

• C3 Basic series
• 2/3” Monochrome progressive scan camera
• 2456 (h) x 2058 (v) active pixels
• 3.45 µm square pixels
• 15 frames/second with full resolution
• Partial scan
• Pre-processing functions inside the camera
• Camera Link interface

Download Product PDF:

• JAI BM-500 Camera

TECHNICAL INFORMATION:

• Sensor: 2/3” progressive scan CCD
• Pixel Clock: 60 MHz
• Frame rate full frame: 15 frames/sec.
• Active area: 8.47 (h) x 7.10 (v)
• Cell size: 3.45 (h) x 3.45 (v)
• Active pixels: 2456 (h) x 2058 (v)
• Color (BB-500 CL): Raw Bayer output, host based interpolation
• Read-out modes -
  Full: 2456 (h) x 2058 (v) 15 fps
  1/2 partial scan: 2456 (h) x 1028 (v) 24 fps
  1/4 partial scan: 2456 (h) x 514 (v) 34 fps
  1/8 partial scan: 2456 (h) x 258 (v) 43 fps
  2/3 partial scan: 2456 (h) x 1372 (v) 20 fps
  Vertical binning: 2456 (h) x 1039 (v) 22 fps (BM-500 CL only)
• Sensitivity (BM-500 CL): 0.34 Lux (On sensor, max. gain, shutter off, 50% video)
• Sensitivity (BB-500 CL): 1.0 Lux (On sensor, max. gain, shutter off, 50% video)
• S/N ratio: >50 dB (0 dB gain)
• Video output: Camera Link, 8-bit, 10-bit or 12-bit
• Auto-iris lens video output: 0.7 VP-p, enabled by internal switch
• Gain: Manual Range -3 to 12 dB
• Synchronization: Int. Internal X-tal
• Inputs -
  Camera Link: Ext. trigger, LVDS, (CC 1)
  TTL: Ext. Trigger 4V ±2V
• Outputs -
  Camera Link: Clk., FVAL, LVAL, Data, EEN
  TTL: XEEN
• Trigger modes: Pre Select, Pulse Width
• Operating Temperature: -5°C to +45°C
• Power: 12V DC ± 10%. 4 W
• Lens mount: C-mount
• Dimensions (H x W x L): 55 x 55 x 55
• Weight: 200 g
