Computar M1218FIC-MP C Mount Lens


Need Help Finding the Best Lens for Your Solution? Call (631) 254-2600
5 Megapixel 2/3" 12mm, F1.8, Manual Iris, C Mount Lens
- Over 5.0 Megapixel
- Full HD Format
- 12mm 2/3” C Mount
- Manual Iris
- Peak performance at long distance
- Designed for ITS & Security applications
Download Product PDF:
TECHNICAL INFORMATION:
- Focal Length: 12mm
- Max. Aperture Ratio: 1:1.8
- Max. Image Format: 6.6mm x 8.8mm(11mm)
- Operation Range:
Iris: F1.8 - F16C
Focus: 1m - lnf. - Angle of View, 2/3 Type:
(D) 48.0o
(H) 39.3o
(V) 30.0o - Angle of View, 1/2 Type:
(D) 36.0o
(H) 29.1o
(V) 22.0o - Angle of View, 1/3 Type:
(D) 27.4o
(H) 22.0o
(V) 16.6o - Operating Temperature: -10o - + 50oC
- Effective Lens Aperture:
Front: 20.0mm
Rear: 13.2mm - Back Focal Length: 15.0mm
- Flange Back Length: 17.526mm
- Mount: C-Mount
- Filter Size: M40.5 × 0.5
- Dimensions: 47.5mm×45mm
- Weight: 132.2 g
Aperture: | 1.8 ~ 16 |
---|---|
Focal Length: | 12mm |
Format : | 2/3 |
Manufacturer: | Computar |
Model Type: | Fixed Focal |
Mount: | C Mount |
Product Life Cycle: | New Product |
Resolution : | 5 MP |
Ruggedized: | -- |
