Computar M5028-MPW2 C Mount Lens

2/3" 50mm F2.8 5 Megapixel Ultra Low Distortion Lens (C Mount)

Dedicated design emphasis on the performance for close-up applications required in factory automation and image processing areas.

• Ultra low distortion
• Higher relative illumination rate
• Floating design
• Locking set screws for focus and iris

Download Product PDF:

• Computar M5028-MPW2

TECHNICAL INFORMATION:

• Focal Length: 50mm
• Max. Aperture Ratio: 1:2.8
• Max. Image Format: 8.8mm x 6.6mm(11mm)
• Operation Range:
  Iris: F2.8 - F32.0
  Focus: 0.4m - Inf.
• Object Dimension at M.O.D.:
  2/3 Type: 4.78cm x 6.38cm
  1/1.8 Type: 3.77cm x 5.00cm
  1/2 Type: 3.48cm x 4.64cm
• Angle of View, 2/3 Type:
  (D) 12.5^o
  (H) 10.0^o
  (V) 7.5^o
• Angle of View, 1/1.8 Type:
  (D) 9.9^o
  (H) 7.9^o
  (V) 5.9^o
• Angle of View, 1/2 Type:
  (D) 9.1^o
  (H) 7.3^o
  (V) 5.5^o
• Operating Temperature: -10^o - + 50^oC
• Effective Lens Aperture:
  Front: 18.0mm
  Rear: 12.0mm
• Back Focal Length: 27.7mm
• Flange Back Length: 17.526mm
• Mount: C-Mount
• Filter Size: M27.0 P=0.5mm
• Dimensions: 29mm x 45.36mm
• Weight: 69.0g
