Fujinon HF12.5HA-1B C Mount Lens

• Design achieving the high resolution, supporting up to 1.5 mega pixel cameras.
• Designed for low distortion, enabling faithful image input.
• Compact, lightweight and robust design, supporting various systems.
• Focus & iris lock tab provided, supporting environments such as vibration.

TECHNICAL INFORMATION:

• Focus: Manual
• Iris: Manual
• Focal Length (mm): 12.5
• Iris Range: F1.4 ~ F16
• Back Focal Distance (in air) (mm): 15.09
• Exit Pupil Position (From Image Plane) (mm): -31.3
• Filter Thread (mm): M25.5 x 0.5
• Mass (g): 45
• Focusing Range (From Front Of The Lens) (m): ~ 0.1
• Angle of View:
  2/3" - 38^o47' x 29^o 35'
  1/2" - 28^o 43' x 21^o 44'
  1/3" - 21^o 44' x 16^o 23'
• Object Dimensions at M.O.D. (H x V) (mm):
  2/3" - 78 x 58
  1/2" - 57 x 42
  1/3" - 42 x 32
• Mount: C
