Sony IMX 264LLR Sensor

Diagonal 11.1 mm (Type 2/3) Approx. 5.07M-Effective Pixel Monochrome and Color CMOS Image Sensor

CMOS Image Sensors with a 3.45 μm Pixel and Global Shutter Function for Industrial Applications

Industrial applications demand imaging of fast-moving subjects. However, there is the issue that existing CMOS image sensors are unable to accurately identify fast-moving subjects due to focal plane distortion and flash band phenomenon as a result of rolling shutter operation. To address this issue, Sony has developed CMOS image sensors with a global shutter function and a 3.45 μm pixel that is the smallest class in the industry. This small-sized 3.45 μm pixel realizes higher sensitivity and lower noise than that of the existing 5.86 μm pixel products, and achieves high picture quality, high resolution and high-speed imaging without focal plane distortion. In addition, these new CMOS image sensors are equipped with a variety of functions such as a trigger mode that arbitrarily controls the storage time using an external trigger signal, and ROI (region of interest) mode.

TECHNICAL INFORMATION:

• Global shutter function
• The industry's smallest pixel size class for industrial applications (3.45 μm)
• High sensitivity (1.1 times compared to the existing 5.86 μm product)
• Max frame rate : 35.7 frame/s (12 bit, IMX264) 55.6 frame/s (12 bit, IMX265)
• A variety of functions (external trigger mode, 1 area ROI mode, supports multiple frame set output, etc.)
