Sony IMX461ALR Sensor

Diagonal 55 mm (Type 3.4) CMOS Image Sensor with Square Pixel for Monochrome Cameras

The IMX461ALR is a diagonal 55 mm (Type 3.4) CMOS active pixel type image sensor with a square pixel array and 102 M effective pixels. This IC incorporates maximum 36 dB PGA circuit and 16-bit A/D converter. 16-bit digital output makes it possible to readout the signals of 102 M effective pixels at high-speed of 2.7 frame/s in still picture mode.

In addition, vertical subsampling binning and horizontal pixel binning realize high-speed 12-bit digital output for shooting moving picture. This sensor is designed for use in consumer use digital still camera. When using this for another application, Sony Semiconductor Solutions Corporation does not guarantee the quality and reliability of this product. Therefore, don't use this for applications other than consumer use digital still camera.

In addition, individual specification change cannot be supported because this is a standard product. Consult your Sony Semiconductor Solutions Corporation sales representative if you have any questions.

TECHNICAL INFORMATION:

• Type 3.4 CMOS active pixel type dots
• Input clock frequency 72 MHz
• All-pixel readout mode
• Various readout modes (*)
• Rolling shutter function moving picture mode
• H driver, V driver and serial communication circuit on chip
• +36 dB gain settable by monochrome in CDS/PGA on chip
• Built-in 11-bit/12-bit/14-bit/16-bit A/D converter
• 8 Lane SLVS-EC output
• Back-illuminated type
